Source CAD and quotation facts
- SEO sequence: PFMOLD-CAD-00115
- Source CAD: adcq_1.stp
- Source path: PF102-5-8整机+单个零件+BOM-20240730/PF102-5-8整机+单个零件+BOM-20240730/PF102-7/单个零件/adcq_1.stp
- File type: STP
- File size: 259 KB
- Estimated process: Die casting
- First material assumption: ADC12
- Application field: Custom Plastic Parts
- Product use: Precision Plastic Component
- Manufacturing keyword: Die Casting Mold Manufacturing
- Parsed part envelope: 26.7 x 168.3 x 26.8 mm
- Projected area reference: 4,510 mm2
- Mesh count / triangles: 1 / 7,856
Safe CAD view images
3D engineering parameters
- Part envelope
- 26.7 x 168.3 x 26.8 mm
- Projected area reference
- 4,510 mm2
- Mesh count
- 1
- Triangle count
- 7,856
PFMOLD engineering notes
PFMOLD reviews alloy selection, wall thickness balance, ejector layout, slide structure and trimming requirements.
Die casting quote assumptions include cavity count, insert steel, surface treatment, cycle time, die weight and export packing.
The generated product page keeps the CAD source, inferred process and engineering parameters together for later sales review.
For SEO and traceability, this page records the real source file name, extension, file size and inferred manufacturing route.
Sales can connect this page with a quote project, DFM note, mold-base selection, packaging size and export shipment record.
