Source CAD and quotation facts
- SEO sequence: PFMOLD-CAD-00095
- Source CAD: 03-asm_asm_14_asm.stp
- Source path: PF.172-吹风机挂墙支架简洁版318/PF.172-吹风机挂墙支架简洁版318/03-asm_asm_14_asm.stp
- File type: STP
- File size: 736 KB
- Estimated process: Injection molding
- First material assumption: ABS
- Application field: Mechanical Plastic Parts
- Product use: Bracket Holder Functional Component
- Manufacturing keyword: Plastic Injection Precision Mold Manufacturing
- Parsed part envelope: 69.4 x 69.4 x 10.5 mm
- Projected area reference: 4,816 mm2
- Mesh count / triangles: 2 / 8,820
Safe CAD view images
3D engineering parameters
- Part envelope
- 69.4 x 69.4 x 10.5 mm
- Projected area reference
- 4,816 mm2
- Mesh count
- 2
- Triangle count
- 8,820
PFMOLD engineering notes
PFMOLD reviews wall thickness, ribs, bosses, draft angle, gate location and parting line before confirming the mold quotation.
The quoting record can be connected with cavity count, runner type, steel grade, mold size, mold weight and export packing assumptions.
This page is generated from a real CAD source file so the content can be linked back to engineering and quotation records.
For SEO and traceability, this page records the real source file name, extension, file size and inferred manufacturing route.
Sales can connect this page with a quote project, DFM note, mold-base selection, packaging size and export shipment record.
