Source CAD and quotation facts
- SEO sequence: PFMOLD-CAD-00042
- Source CAD: 240702-17-004.step
- Source path: 2025 02结构件出图文件/3D打印件5N.M/240702-17-004.step
- File type: STEP
- File size: 1,737 KB
- Estimated process: Injection molding
- First material assumption: ABS
- Application field: Custom Plastic Parts
- Product use: Precision Plastic Component
- Manufacturing keyword: Plastic Injection Precision Mold Manufacturing
- Parsed part envelope: 11.1 x 11.2 x 52 mm
- Projected area reference: 582 mm2
- Mesh count / triangles: 1 / 9,852
